0.15mm Narrow Slot Wire EDM

0.15mm Narrow Slot Wire EDM is a precision manufacturing service based on high-precision slow wire cutting technology. Xincheng specializes in machining ultra-fine slit structures with a width of only 0.15mm on metal workpieces. With its core advantages of "micron-level slit control, mirror-like surface finish, and high-stability shape and position," it has become a key processing solution in high-end manufacturing fields such as aerospace, precision molds, and electronic components.

Send Inquiry

Product Description

Processing Technology and Precision Advantages

The 0.15mm Narrow Slot Wire EDM utilizes imported slow wire cutting equipment (such as Sodick and Charmilles), paired with brass/galvanized electrode wires with a diameter of 0.03-0.1mm. High-frequency pulse discharge removes metal, and an adaptive servo control system achieves precise narrow slot forming. Core precision indicators are industry-leading:

Dimensional Accuracy: Slot width tolerance is strictly controlled within ±0.002mm, and slot length and depth errors are ≤0.003mm, meeting GB/T standards. Standard 13916-2008 Precision Grade Requirements.Surface Quality: The surface roughness of the inner wall of the narrow slot can reach Ra0.2-0.4μm, presenting a uniform mirror effect. Direct assembly is possible without subsequent polishing, avoiding workpiece wear or signal interference caused by surface roughness.

Geometric Tolerances: Slot straightness ≤0.001MM/100MM, parallelism ≤0.002MM, adjacent slot spacing tolerance ≤0.003MM, ensuring consistency of the multi-slot structure.Machining Stability: Utilizing water-soluble working fluid and a closed-loop filtration system reduces electrode wire vibration and discharge interference. Single slot machining pass rate ≥99.2%, batch production dimensional fluctuation ≤0.0015MM.

Xincheng is a professional CNC machining factory and also a manufacturer and supplier of processed parts in China. Welcome to consult and purchase.

Adaptable Material and Process Characteristics

Adapted Material	Material Properties	Processing Highlights
Mold Steel (SKD11, Cr12MoV)	High Hardness, High Wear Resistance	Utilizes segmented discharge technology to reduce machining stress and prevent edge chipping in narrow slits.
Stainless Steel (304, 316L)	Corrosion Resistance, Good Toughness	Optimizes working fluid ratio to improve surface finish and prevent rust after machining.
Titanium Alloy (TC4)	High Strength, Poor Thermal Conductivity	Employs a real-time temperature control system to avoid heat accumulation and prevent deformation of narrow slits.
Copper Alloy (Copper, Beryllium Copper)	Good Electrical Conductivity, Easy to Machine	Uses low-energy discharge parameters to protect the accuracy of the inner walls of narrow slits and reduce electrode wire wear.

Application Scenarios

The 0.15mm Narrow Slot Wire EDM product, with its core advantages of "ultra-fine width + high precision," is widely used in high-end manufacturing fields with stringent structural precision requirements. Typical applications include:

1. Precision Mold Manufacturing: Used for lead slots in semiconductor packaging molds and terminal forming seams in connector molds, ensuring precise pin and terminal forming and consistent insertion and removal, extending mold lifespan to over 500,000 cycles.

2. Aerospace Components: Processing cooling slots for aero-engine blades and signal transmission seams for sensor housings, ensuring cooling efficiency and signal transmission stability, meeting aerospace-grade reliability standards.

3. Electronic Components: Used for commutator slots in micro-motors and heat dissipation slots in precision resistors, reducing component size while improving heat dissipation performance, adapting to the "miniaturization and high integration" trend in consumer electronics.

4. Medical Equipment Accessories: Processing guide slots for minimally invasive medical devices and detection probe slots for diagnostic instruments, ensuring instrument operation precision and detection accuracy, meeting medical-grade biocompatibility requirements.

Service Guarantee and Customization Capabilities

To meet the personalized needs of different customers, we provide full-process precision machining services, with the following core guarantees:

Customization Support: We can customize the length, depth, arrangement, and related structures of narrow slots based on customer-provided 2D drawings (CAD) and 3D models (STEP/IGES). The minimum machined narrow slot width is 0.1mm, and the maximum single-batch processing quantity is 1000 pieces/batch.

Quality Inspection System: Each batch of products undergoes full-dimensional inspection using a coordinate measuring machine, tool microscope, and surface roughness tester, providing detailed inspection reports to ensure traceable quality.

Delivery Cycle: Standard parts processing takes 3-5 working days, and customized parts take 5-10 working days depending on complexity. We support expedited services for urgent orders, with delivery as fast as 48 hours.

After-Sales Service: We provide machining process consultation and installation adaptation suggestions. In case of non-human-caused quality problems, we support free rework or returns/exchanges.
