0.15mm Round Hole Wire EDM

Technical Advantages

The 0.15mm Round Hole Wire EDM service utilizes imported slow wire cutting equipment (such as Sodick and Charmilles), paired with brass/galvanized electrode wires with a diameter of 0.03-0.1mm. High-frequency pulse discharge removes metal, and an adaptive servo control system achieves precise hole forming through narrow slit and center positioning technology. Core precision indicators are industry-leading:

- Dimensional Accuracy: Slit width tolerance is strictly controlled within ±0.002mm, and slit length and depth dimensional errors are ≤0.003mm, meeting the precision-grade requirements of GB/T 13916-2008;

- Dimensional Accuracy: Hole diameter tolerance is strictly controlled within ±0.002mm, and hole depth dimensional errors are ≤0.003mm, meeting the precision-grade requirements of GB/T 13916-2008;

- Surface Quality: The surface roughness of the inner wall of the narrow slot can reach Ra0.2-0.4μm, presenting a uniform mirror effect. It can be directly assembled without subsequent polishing, avoiding workpiece wear or signal interference caused by surface roughness.

- Surface Quality: The surface roughness of the inner wall of the round hole can reach Ra0.2-0.4μm, presenting a uniform mirror effect. It can be directly assembled without subsequent polishing, avoiding component wear or media blockage caused by surface roughness.

- Geometric Tolerances: Slot straightness ≤0.001MM/100MM, parallelism ≤0.002MM, adjacent slot spacing tolerance ≤0.003MM, ensuring the consistency of the multi-slot structure.

- Geometric Tolerances: Roundness of round holes ≤0.001MM, concentricity ≤0.002MM, adjacent round hole center distance tolerance ≤0.003MM, ensuring the assembly consistency of the multi-hole structure.

- Processing stability: Utilizing a water-soluble working fluid and a closed-loop filtration system reduces electrode wire vibration and discharge interference, achieving a single narrow slit processing pass rate ≥99.2%, and batch production dimensional fluctuation ≤0.0015mm;

Processing stability: Utilizing a water-soluble working fluid and a closed-loop filtration system reduces electrode wire vibration and discharge interference, achieving a single round hole processing pass rate ≥99.2%, and batch production dimensional fluctuation ≤0.0015mm.

Typical Applications

The 0.15mm Round Hole Wire EDM, with its core advantages of "ultra-fine aperture + high precision," is widely used in high-end manufacturing fields with stringent structural precision requirements:

1. Precision Mold Manufacturing: Used for lead slots in semiconductor packaging molds and terminal forming seams in connector molds, ensuring precise forming and insertion/removal consistency of pins and terminals, extending mold life to over 500,000 cycles;

2. Precision Mold Manufacturing: Used for pin holes in semiconductor packaging molds and terminal positioning holes in connector molds, ensuring precise assembly and insertion/removal consistency of pins and terminals, extending mold life to over 500,000 cycles;

3. Aerospace Components: Machining cooling slits in aero-engine blades and signal transmission slots in sensor housings, ensuring cooling efficiency and signal transmission stability, meeting aerospace-grade reliability standards;

4. Aerospace Components: Machining signal pin holes in aerospace sensors and damping orifices in hydraulic valve cores, ensuring signal transmission stability and hydraulic control precision, meeting aerospace-grade reliability standards;

5. Electronic Components: Used for narrow slits in commutators of micro-motors and heat dissipation slits in precision resistors, reducing component size while improving heat dissipation performance, aligning with the trend of "miniaturization and high integration" in consumer electronics;

6. Electronic Components: Used for brush positioning holes in micro-motors and lead holes in precision capacitors, reducing component size while improving conductivity, aligning with the trend of "miniaturization and high integration" in consumer electronics;

7. Medical Equipment Accessories: Processing guide slits in minimally invasive medical devices and probe slits in diagnostic instruments, ensuring instrument operation precision and testing accuracy, meeting medical-grade biocompatibility requirements.

8. Medical Equipment Accessories: Processing guide wire holes in minimally invasive medical devices and probe holes in diagnostic instruments, ensuring instrument operation precision and testing accuracy, meeting medical-grade biocompatibility requirements.

Service Guarantee

To meet the personalized needs of different customers, we provide end-to-end precision 0.15mm Round Hole Wire EDM service. Our core guarantees are as follows:

- Customization Support: We can customize the length, depth, arrangement, and related structures of narrow slots based on customer-provided 2D drawings (CAD) and 3D models (STEP/IGES). The minimum machined slot width is 0.1mm, and the maximum single-batch processing quantity is 1000 pieces/batch.

- Customization Support: We can customize the diameter tolerance, hole depth, arrangement, and related structures of round holes based on customer-provided 2D drawings (CAD) and 3D models (STEP/IGES). The minimum machined round hole diameter is 0.1mm, and the maximum single-batch processing quantity is 1000 pieces/batch.

- Quality Inspection System: Each batch of products undergoes full-dimensional inspection using a coordinate measuring machine, tool microscope, and surface roughness tester. Detailed inspection reports are provided to ensure quality traceability.

- Delivery cycle: Standard parts processing cycle is 3-5 working days; customized parts processing cycle is 5-10 working days depending on complexity. Urgent orders can be expedited with delivery as fast as 48 hours.

- After-sales service: We provide processing technology consultation and installation adaptation suggestions. In case of non-human-caused quality problems, we support free rework or returns/exchanges.
