Metal Stamping Die Template

Metal Stamping Die Template is a specialized equipment for stamping sheet metal parts, primarily used in the mass production of complex parts in the automotive, electronics, and home appliance industries. Core processes include punching, bending, and forming. It can be categorized by process into four types: blanking dies, bending dies, drawing dies, and forming dies; and by the degree of process combination into single-operation dies, compound dies, and progressive dies.

Inspection Standards

The inspection standards for Metal Stamping Die Template can be mainly divided into the following aspects:

1. Part Drawings/Inspection Instructions: Some simple metal stamping parts can be inspected by comparing them with the dimensions marked on the drawings. Secondly, the use of various measuring instruments is crucial, including basic measuring tapes, calipers, micrometers, dial indicators, go/no-go gauges, etc. Attention should also be paid to important tolerances marked on the drawings, ensuring that the tolerance range is consistent with the drawings. For high-precision products, strict tolerance requirements are essential.

2. Specialized Inspection Fixtures: These are determined based on the actual condition of the parts and require proficiency in their use.

3. Sample Parts: For some parts without inspection fixtures but with complex shapes that cannot be represented by two-dimensional drawings. A double circle inspection can be used. The stamping plate is the most direct reference point, showing whether the structure is OK, the surface treatment, and any burrs.

4. Material defects.

The above are the inspection standards for Metal Stamping Die Templates. For a beginner, these aspects are sufficient, but more importantly, familiarity with the stamping process and experience are needed. For example, in appearance inspections, burrs on the product surface are absolutely unacceptable. Burrs not only affect the appearance but also pose a threat to human safety, requiring extensive experience.
